biomass rotary dryer
The Best Choices for Your Project
- Customization Service：The maximum customizable diameter is 3.5 meters
- Solution：Provide solutions for your problems
- Dryer length: 8 meters to 50 meters.
What is a Biomass Rotary Dryer?
A Biomass Rotary Dryer is an industrial drying system specifically engineered to reduce the moisture content of bulk biomass materials through a direct or indirect heat transfer process within a rotating cylinder. It is the most efficient and reliable method for handling large volumes of diverse, often irregular, biomass feedstocks. By removing excess water, the dryer transforms wet, raw biomass into a stable, high-quality, and energy-dense product suitable for fuel, composting, or other value-added applications.
The operation is continuous and highly efficient, based on a simple yet effective mechanical process:
Feeding: Wet biomass is uniformly fed into the elevated end of a slightly inclined, rotating drum.
Tumbling and Showering: As the drum rotates, a series of internal fins (called flights) lift the material and cascade it down as a continuous “curtain” or shower across the entire cross-section of the drum.
Heat Transfer: A stream of hot gases, generated by a furnace, is forced through the drum. This hot air flows directly through the showering curtain of biomass particles (in a direct-contact dryer), rapidly transferring heat and causing moisture to evaporate.
Drying and Discharge: The tumbling action ensures every particle is repeatedly exposed to the hot air, leading to uniform and consistent drying. The dried biomass moves toward the lower end of the drum due to gravity and the inclination, where it is discharged for collection.
The following table outlines our standard range of rotary drum dryers for biomass. We specialize in customizing these parameters based on your specific biomass type, initial/final moisture content, and production capacity.
| Category | Specification | Model BRD-1512 | Model BRD-1815 | Model BRD-2420 | Model BRD-3025 | Notes |
|---|---|---|---|---|---|---|
| Drum Specifications | Drum Diameter (m) | 1.5 | 1.8 | 2.4 | 3.0 | Custom diameters available. |
| Drum Length (m) | 12 | 15 | 20 | 25 | Custom lengths available. | |
| Rotation Speed (rpm) | 3-8 | 2-6 | 2-5 | 1.5-4 | Adjustable via Variable Frequency Drive (VFD). | |
| Inclination (%) | 2-5 | 2-5 | 2-5 | 2-5 | Adjustable for retention time control. | |
| Performance & Capacity | Evaporation Capacity (kg H₂O/h) | 800 – 1,200 | 1,500 – 2,200 | 3,000 – 4,500 | 6,000 – 8,500 | Primary performance metric. |
| Wet Biomass Throughput (t/h)* | 2.5 – 4.0 | 5.0 – 7.5 | 10 – 15 | 18 – 28 | *Based on 50% inlet to 10% outlet moisture. | |
| Inlet Moisture Content (max) | 55% | 55% | 55% | 55% | Can be engineered for higher moisture (e.g., 65%). | |
| Outlet Moisture Content | Adjustable (8% – 15%) | Adjustable (8% – 15%) | Adjustable (8% – 15%) | Adjustable (8% – 15%) | Precisely controlled for pelletizing/briquetting. | |
| Thermal System | Heat Source | Biomass, Natural Gas, Diesel, Syngas | Biomass, Natural Gas, Diesel, Syngas | Biomass, Natural Gas, Diesel, Syngas | Biomass, Natural Gas, Diesel, Syngas | Custom burner design for each fuel. |
| Inlet Air Temperature (°C) | 600 – 850 | 600 – 850 | 600 – 850 | 600 – 850 | ||
| Outlet Air Temperature (°C) | 90 – 120 | 90 – 120 | 90 – 120 | 90 – 120 | ||
| Thermal Efficiency | >80% | >80% | >80% | >80% | Achieved via optimized flights & insulation. | |
| Drive & Power | Main Motor Power (kW) | 11 | 22 | 45 | 90 | |
| Reduction Gearbox | Hardened Helical Gearbox | Hardened Helical Gearbox | Hardened Helical Gearbox | Hardened Helical Gearbox | ||
| Physical & Auxiliary | Operating Weight (tons) | ~18 | ~30 | ~55 | ~95 | Approximate. |
| Floor Space (L x W m) | 16 x 6 | 20 x 7 | 26 x 9 | 35 x 11 | Includes ancillary equipment. | |
| Key Features | Specialized Design | – Anti-adhesion flights – Abrasion-resistant lining – Insulated shell – PLC Control Panel | – Anti-adhesion flights – Abrasion-resistant lining – Insulated shell – PLC Control Panel | – Anti-adhesion flights – Abrasion-resistant lining – Insulated shell – Advanced PLC/SCADA – Heat Recovery Option | – Anti-adhesion flights – Abrasion-resistant lining – Insulated shell – Advanced PLC/SCADA – Heat Recovery Option | |
| Dust Control | Standard System | Cyclone Separator | Cyclone Separator + Bag Filter Pre-filter | Cyclone Separator + Bag Filter | Cyclone Separator + Bag Filter | Optional Wet Scrubber for fine particles. |
Explanation of Key Parameters:
Model Naming Convention: BRD-XXYY, where “BRD” stands for Biomass Rotary Dryer, “XX” indicates the drum diameter in decimeters, and “YY” indicates the drum length in meters. (e.g., BRD-1815 = 1.8m Diameter x 15m Length).
Evaporation Capacity (kg H₂O/h): This is the most critical performance metric. It defines the dryer’s ability to remove water and is more consistent for comparison than wet biomass throughput, which varies with initial moisture.
Anti-Adhesion Flight Design: Unlike standard dryers, our biomass dryers feature specially designed internal flights that prevent sticky, fibrous biomass (like wet sawdust or agro-waste) from building up on the drum walls, ensuring continuous, stable operation.
High Thermal Efficiency (>80%): Achieved through:
Optimized Flight Design: Creates an optimal “curtain” of material for maximum heat transfer.
Effective Insulation: Minimizes radiant heat loss.
Heat Recovery (Optional): Recycles thermal energy from the exhaust gas to pre-heat combustion air, drastically reducing fuel consumption.
Fuel Flexibility: The dryer can be paired with a dedicated biomass burner, allowing you to use your own low-value biomass (e.g., siftings, bark) as fuel, creating a highly cost-effective and sustainable operation.
Biomass Materials Suitable for Drying
Our rotary dryers are versatile and can process a wide array of biomass feedstocks, including:
Wood-Based Biomass: Sawdust, wood chips, wood shavings, bark, timber off-cuts.
Agricultural Residues: Straw, rice husks, corn stalks, wheat bran, sugarcane bagasse.
Energy Crops: Miscanthus, switchgrass, and other purpose-grown grasses.
Agro-Industrial Waste: Fruit stones, olive pomace, coffee husks.
Other Organic Materials: Animal manure for fertilizer, digestate from biogas plants.
Applications of Dried Biomass
Drying biomass significantly enhances its value and opens up multiple application channels:
Biomass Fuel Production: The primary use. Dried biomass is pelletized or briquetted to create high-quality, uniform solid biofuels for boilers and heating systems.
Co-firing in Power Plants: Replaces a portion of coal with biomass, reducing carbon emissions.
Animal Bedding: Dried sawdust and shavings provide excellent, absorbent bedding.
Organic Fertilizer & Soil Amendment: Dried manure and compost are stabilized and easier to package and spread.
Feedstock for Biorefineries: Used in the production of biofuels like bioethanol or biochemicals.
Key Features and Advantages
Our Biomass Rotary Dryers offer distinct benefits over other drying technologies:
High Capacity & Efficiency: Capable of processing several tons of material per hour continuously.
Robust Construction: Built with durable, often wear-resistant materials to withstand abrasive biomass materials.
Superior Drying Uniformity: The tumbling action ensures all particles are evenly dried, preventing case-hardening (a hard, dry shell with a wet interior).
Fuel Flexibility: Can be coupled with various cost-effective heat sources (see below).
Handles Variable Feedstock: Tolerates fluctuations in initial moisture content and particle size better than many other dryer types.
Heat Source Options
We provide flexible heat source solutions to match your local fuel availability and cost:
Direct Biomass Firing: The most common and economical choice. Uses a dedicated biomass burner (e.g., with wood chips, sawdust) to generate hot gas.
Natural Gas / Propane: Clean, easy to control, and produces consistent heat with low emissions.
Oil-Fired Systems: Suitable for locations without a reliable gas supply or biomass source.
Steam (Indirect Drying): Uses steam-heated coils inside the drum, ideal for heat-sensitive materials where combustion gases cannot contact the product.
Biogas / Syngas: Utilizes gas produced from anaerobic digesters or gasifiers for a sustainable, closed-loop solution.
Hot Flue Gases: Can be integrated with existing boiler systems.
Level of Automation
Our dryers can be equipped with sophisticated control systems to minimize labor and optimize performance:
Basic Control Panel: Start/stop functions and basic temperature monitoring.
Semi-Automated (PLC): Monitors and controls drum speed, temperature, and airflow. Includes alarm functions.
Fully Automated (PLC/SCADA): Fully integrated control for the entire drying line (dryer, feeder, burner, conveyor). Features touch-screen HMI, data logging, remote monitoring, and automatic adjustment of parameters to maintain consistent final moisture content.
Customized Drying Solutions
We do not believe in a one-size-fits-all approach. Our engineering team designs tailor-made solutions based on a detailed analysis of your specific requirements:
Raw Material Analysis: We test your biomass to understand its initial moisture, particle size distribution, abrasiveness, and flow characteristics.
Capacity Requirement: We design the dryer size and configuration to meet your target hourly or annual production.
Desired Final Moisture: The system is engineered to consistently achieve your required moisture level (e.g., 10-15% for pelletizing).
Site and Infrastructure: We consider your available space, power supply, and fuel availability.
Budget and ROI: We provide solutions that balance performance with investment and operational costs.
