Rice husk dryer
The Best Choices for Your Project
We are a rice husk dryer manufacturer, specializing in providing you with rice husk drying solutions
- Production capacity: 1-20T/H.
- Customizable diameter from 80cm to 3600cm.
- Dryer length: 8 meters to 36 meters.
Rice husk dryer
Rice husk is the protective outer shell of rice grains. The inside is edible rice, while the outside is the husk.
Rice husk contains a large amount of cellulose and lignin, making it combustible. Instead of being discarded, rice husk can be widely utilized in industrial, energy, and agricultural fields.
Rice husk, when dried with a specialized dryer, has many valuable applications:
Clean Energy
Dried rice husk can be processed into biomass fuel pellets, which replace coal and can be used in power plants and boilers as a clean and renewable energy source.
Organic Fertilizer Additive
Rice husk serves as a high-quality auxiliary material for organic fertilizers. When mixed with livestock manure (cattle, sheep, etc.), it effectively absorbs excess moisture during fermentation.Animal Feed Ingredient
Rice husk can be used as a feed additive, increasing crude fiber content in animal feed.
Industrial Applications
Rice husk can be processed into activated carbon, building material fillers, insulation materials, and more.
| Model | Daily Capacity (t/d) | Drying Capacity (t/h) | Inlet Moisture (%) | Outlet Moisture (%) | Drying Temperature (°C) | Total Power (kW) | Total Weight (kg) | Floor Area (㎡) |
|---|---|---|---|---|---|---|---|---|
| JHD-1210 | 44.0 – 19.5 | 0.565 | 35–50% | 4–15% | 370 ± 100 | 28 | 13,500 | 5 × 15 |
| JHD-1409 | 46.5 – 20.5 | 0.595 | 34% | — | — | — | 15,500 | 5 × 15 |
| JHD-1615 | 88.0 – 39.0 | 1.130 | 45% | — | — | — | 19,500 | 6 × 22 |
| JHD-2010 | 144.5 – 63.5 | 1.850 | 78% | — | — | — | 25,000 | 8 × 18 |
| JHD-2210 | 154.0 – 67.5 | 1.976 | 85% | — | — | — | 27,000 | 10 × 18 |
| JHD-2510 | 193.0 – 83.5 | 2.427 | 110% | — | — | — | 35,000 | 10 × 18 |
| JHD-2512 | 227.0 – 100.0 | 2.912 | 125% | — | — | — | 38,000 | 10 × 20 |
| JHD-2912 | 268.0 – 120.0 | 3.432 | 135% | — | — | — | 43,500 | 10 × 22 |
Rice husk dryer
Rice husk is the protective outer shell of rice grains. The inside is edible rice, while the outside is the husk.
Rice husk contains a large amount of cellulose and lignin, making it combustible. Instead of being discarded, rice husk can be widely utilized in industrial, energy, and agricultural fields.
What is the Purpose of Drying Rice Husk?
Rice husk, when dried with a specialized dryer, has many valuable applications:
Clean Energy
Dried rice husk can be processed into biomass fuel pellets, which replace coal and can be used in power plants and boilers as a clean and renewable energy source.
Organic Fertilizer Additive
Rice husk serves as a high-quality auxiliary material for organic fertilizers. When mixed with livestock manure (cattle, sheep, etc.), it effectively absorbs excess moisture during fermentation.Animal Feed Ingredient
Rice husk can be used as a feed additive, increasing crude fiber content in animal feed.
Industrial Applications
Rice husk can be processed into activated carbon, building material fillers, insulation materials, and more.
Working Principle of Rice Husk Dryer
Our rice husk dryers use hot air drying technology to reduce the moisture content of rice husk to as low as 1%. The process works as follows:
Heat Source
The hot air furnace burns fuels such as coal, biomass pellets, or electricity to generate heat. The high-temperature flue gas enters the mixing air chamber, where it blends with fresh air drawn in under negative pressure, creating a stable and precisely controlled drying medium—clean hot air.
Feeding System
Rice husk is evenly fed into the dryer by a feeding conveyor. Under the suction of the induced draft fan, hot air enters the rotary drum at a controlled velocity, contacting the rice husk in either co-current (parallel flow) or counter-current (opposite flow) mode.
(Note: Co-current flow is often preferred to prevent material scorching near the inlet.)
Drying Process
Inside the drum, rice husk is lifted and scattered repeatedly by lifters, ensuring full contact with the hot air. Heat is transferred by convection to the rice husk surface and by conduction into the inner layers. Moisture migrates from the inside to the surface, continuously evaporating. Meanwhile, dust collection equipment removes impurities and ensures environmental compliance.
Discharge
The dried rice husk is automatically discharged by the outlet system and can be packaged with a ton-bag packing machine for easy storage and transport.
In short, the process follows:
Feeding → Lifting & Scattering → Hot Air Contact → Moisture Evaporation → Discharging & Cooling
Features of Rice Husk Dryer
Wide Application Range
Not only suitable for rice husk, but also for sawdust, wood chips, bark, straw, coconut shell, peanut shell, palm empty fruit bunches, and other biomass materials.
High Efficiency
Designed for 24-hour continuous operation, capable of processing from dozens to hundreds of tons per day. The hot air drying technology ensures rapid moisture removal.
High Automation
Equipped with an advanced control system to monitor temperature, humidity, and other parameters in real time. One-button operation, easy to use, and labor-saving.
Why Choose Us as Your Rice Husk Dryer Manufacturer?
Global Leadership
We are a leading manufacturer of rice husk dryers worldwide. Based on the different moisture contents of raw materials, we provide customized drying solutions for each client.
Quality Assurance
Our rice husk dryers are certified by ISO9001 Quality Management System. Core components are made of high-temperature and wear-resistant materials, extending the service life of the equipment.
Environmental Protection
We design our dust collection and environmental systems to be 30% higher than industry standards, ensuring fast and efficient dust removal and eco-friendly performance.
Comprehensive Global After-Sales Service
We provide full support including equipment installation, machine commissioning, operator training, and worldwide technical service. Our dedicated team ensures timely assistance wherever our clients are located.
