Wood Pellet Dryer
The Best Choices for Your Project
Wood pellet dryers can be customized according to customer requirements
- Provide you with cow dung drying solutions
- Solution：Provide solutions for your problems
- Dryer length: 8 meters to 36 meters.
Wood Pellet Dryer
A wood pellet dryer is used to produce wood pellets. It can be used to dry straw, sawdust, rice straw, and wood chip pellets.
In wood pellet production, the wood raw material typically contains a high moisture content after being pressed into pellets by the pelletizer. If not dried, the pellets are prone to mold and sticking, affecting storage and combustion efficiency.
We can produce wood pellet dryers with an hourly output of 0.5 tons to 20 tons, and lengths up to over 30 meters.
The wood pellet dryer uses a drum dryer, employing both single-pass and three-pass drying methods. Hot air is supplied by a burner and then enters the drum for drying.
- Feed: Wet wood chips or pellets enter the drum dryer through a loading system (we can also design forklift loading).
- Hot air contact: Hot air from the burner is continuously fed into the dryer, and the wood pellets rotate up and down inside the dryer, ensuring sufficient contact between the hot air and the dryer. (The burner’s heat source can be electricity, biomass pellets, natural gas, coal, etc.)
- Separation and Discharge: The dried wood chips are discharged from the end of the drum and enter the subsequent cooling and screening system. The exhaust gas, which contains a large amount of water vapor, is purified by environmental protection equipment such as cyclones and bag filters before being discharged into the atmosphere by an induced draft fan.
During the wood pellet drying process, 24-hour uninterrupted production is possible. The inlet air temperature is generally controlled below 700°C, and the discharge temperature is maintained between 60-80°C. Excessive temperatures, which may cause ignition or carbonization of the material and affect pellet quality, are strictly prohibited.
| Model | Φ2.0×6m | Φ2.5×6.5m | Φ3.0×7m | Φ3.2×7m |
|---|---|---|---|---|
| Outer Drum Inner Diameter (m) | 2.0 | 2.5 | 3.0 | 3.2 |
| Outer Drum Length (m) | 6 | 6.5 | 7 | 7 |
| Drum Volume (m³) | 18.84 | 31.89 | 50.26 | 56.30 |
| Drum Speed (rpm) | 4-6.5 | 4-6.5 | 4-6.5 | 4-6.5 |
| Slag Initial Moisture (%) | 20 | |||
| Slag Final Moisture (%) | 1-3 | |||
| Fly Ash Initial Moisture (%) | 20 | |||
| Fly Ash Final Moisture (%) | 1-3 | |||
| Inlet Temperature (°C) | 700-750 | 700-750 | 700-750 | 700-750 |
| Production Capacity (t/h) | Fly Ash: 10-15 | Fly Ash: 15-20 | Fly Ash: 25-35 | Fly Ash: 35-45 |
| Slag: 22-25 | Slag: 30-35 | Slag: 40-50 | Slag: 55-65 | |
| Coal Consumption (kg/h) | 17-24 | 17-20 | 17-20 | 17-20 |
| Motor Model | Y2-160m-4E | Y2-132m-4E | Y2-132m-4E | Y2-160m-4 |
| Motor Power (kW) | 5.5×2 | 7.5×2 | 7.5×4 | 11×4 |
| Reducer Model | XWD-5.5KW-8 | XWD-5.5KW-5 | XWD-7.5KW-8 | XWD-7.5KW-8 |
| Reducer Gear Ratio | 29 | 29 | 29 | 29 |
Applications of Wood Pellet Dryers in Wood Pellet Production
Wood pellet drying equipment is a key piece of equipment in wood pelleting, with the following main applications:
- Improving Pellet Efficiency: Wood raw materials with excessive moisture content will soften the lignin in the pelletizer, making it difficult to form and easily clogging the die holes. Wood is generally dried to a moisture content of around 18%-20%.
- Ensuring Pellet Quality: A stable moisture content is a prerequisite for producing pellet fuel with high density, strength, and calorific value. Uneven drying can lead to fragile pellets and excessive powder.
- Reduced Energy Consumption: The energy consumption required to extrude dry raw materials in a biomass pellet machine is far lower than that required to extrude wet materials. From the perspective of the entire production line, the investment in the drying process effectively reduces the electricity consumption of the pelletizing process.
- Expanding Raw Material Sources: This allows various high-moisture forestry waste and wood processing waste to become high-quality raw materials, turning waste into valuable resources and reducing costs.
Modern professional wood pellet dryers offer the following outstanding features:
High Efficiency and Energy Saving: The dryer utilizes a multi-layered lifting plate design and excellent insulation, ensuring efficient heat exchange and high thermal efficiency, significantly reducing fuel costs.
Stable Operation: The dryer boasts a sturdy structure and strong overload resistance, enabling 24-hour continuous and stable operation, ensuring smooth production lines.
Uniform Drying: The unique lifting plate structure ensures that the material is spread repeatedly without dead spots, resulting in a uniform moisture content in the finished product.
Automated Control: Equipped with an intelligent temperature control system, it monitors and adjusts the inlet air temperature and outlet moisture content in real time, simplifying operation and reducing human error. Safe and Reliable: Integrated explosion-proof and spark-proof designs with multiple safety features eliminate potential safety hazards.
Environmentally Compliant: Equipped with an efficient dust removal system, exhaust emissions meet international environmental standards.
What Kinds of Wood Pellet Dryers Can We Provide?
Choosing us as your partner, you’ll receive more than just a piece of equipment; you’ll receive a comprehensive solution:
Customized Model Options: We offer a variety of dryer models, including single-drum and triple-drum models, and can recommend or customize the most suitable model based on your specific feedstock characteristics (wood species, initial moisture content, and production requirements).
Energy-Efficient Design: Our equipment utilizes a computer-optimized skid plate structure and optimized insulation solutions, resulting in industry-leading thermal efficiency, directly reducing your drying cost per ton of finished product.
Corrosion-Resistant Core Material: Key areas that come into contact with wet wood chips and high-temperature steam are constructed from corrosion- and wear-resistant high-quality stainless steel, extending equipment life and reducing maintenance costs. One-Stop Support: We provide a complete system package, including a hot air furnace, loader, dryer, cyclone dust collector, bag filter, induced draft fan, and electronic control system, ensuring perfect compatibility and optimal performance.
Intelligent Control System: Equipped with an advanced PLC control cabinet, it displays and adjusts parameters such as temperature and speed in real time, enabling one-touch start/stop and fault alarms for simple operation and labor-saving operation.
Worry-Free After-Sales and Technical Support: We provide comprehensive technical support, from site planning and foundation design, installation and commissioning, to operator training. Rapid spare parts supply and after-sales response ensure your production line continues to create value.
